Orbit™ Digital Microtube and Microplate Shakers

Orbit™ P4 Digital Microtube and Microplate Shakers

Compact size makes these digital shakers ideal for incubator use

Choose Products and Accessories below

Product SKU's

SKU Name Description Get a Quote
S2020-P4-B Orbit™ P4 Digital Shaker With platform for 4 microplates

Accessories SKU's

SKU Title Get a Quote
C1205 Adapter for 0.5 mL tubes (6/pack)
C1206 Adapter for 0.4 mL tubes (6/pack)
C1222 Adapter for 0.2 mL tubes (6/pack)
S2020-R Extra workstation/transfer rack for above
Product Specifications
Speed range*100 - 1,200 rpm
Timer0 - 99 min or continuous
Motion/orbit sizeCircular, 3 mm
Maximum capacityM60: 60 x 1.5/2.0 mL microtubes, P2: 2 microplates, P4: 4 microplates
Maximum load0.66 lb/0.3 kg
Ambient operating range+4° to 65°C
Base dimensions (W x D x H)6.6 x 11 x 6 in/16.8 x 27.9 x 15.3 cm
Weight9.5 lb/4.3 kg
Electrical230V~, 50 Hz or 120V~, 60 Hz
*Maximum speed for 115V unit is 1,400rpm

Compact Digital Lab Shaker

The smallest of the Orbit™ Digital Shakers, the P4 features variable speed across a broad range, making it useful for a variety of applications. Both time of operation and shaker speed are set and displayed digitally, with their values shown on the large 3 digit LED. Parameters are selected with an easy turn knob. A sturdy base encloses the motor for quiet, vibration free operation. The unit can be used in temperature controlled environments. Its compact size makes it ideal for incubator use.

  • Large capacity - 4 microplates
  • Resuspending, homogenizing or vortexing
  • Sturdy, compact construction
  • Suitable for cold room or incubator use

The Orbit™ P4 holds four microplates. The unit accepts all sizes of standard microplates, including deep well plates. Retaining springs on the contoured steel platform hold samples in place.

Click to view all of Labnet's lab shakers.
